Distributes Art-Net data to 8 DMX512 universes (4096 channels). Parallel DMX input possible (1024 channels). 8 optically isolated XLR plugs (3-pin) for DMX output. 2 XLR jacks (3-pin) for DMX input. Variable data routing capabilities for all DMX outputs. 2 x Neutrik etherCON in/through port. Serial connection possible. User-friendly configuration directly at the front panel via 4 operating buttons and alphanumeric LCD screen (2 x 16 characters). LED indication for functions. Splitter operation possible. Rack installation 1 U.
Sekce: SVĚTELNÁ TECHNIKA -> Ovladače (kontrolery) -> Rozbočovače
Druh produktu: Art-Net interface distributes 8 universes to XLR
Název produktu: Eurolite Art-Net/DMX Node 8 MK2, 8 kanálový rozdělovač DMX
Značka: Eurolite
Specifikace: Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 5 W
DMX512 inputs: 2 x 3-pin XLR male
DMX512 outputs: 8 x 3-pin XLR female
Ethernet: 2 x RJ45 10/100 Mbps (Neutrik etherCON)
Protocol: Art-Net 3
Dimensions (L x W x H): 483 x 175 x 44 mm
Weight: 2.4 kg
Hmotnost: 2,8 kg
Kod produktu: 70064843
EAN: 4026397634198
Počet kusů skladem: 0
Dodání za: 5 dní
